EmbeddingGemma 2: Text, Code, Images, Video and Audio in One Vector Space

EmbeddingGemma 2 launched on October 6, 2026 under Apache 2.0. It is a sub-1B model built on Gemma 4 that maps text, code, images, video and audio into one 768-dimensional space. This article covers the architecture, the benchmarks, and runnable scripts to provide measured results. Table of contentsSpecificationsHow it works under the hoodBenchmarks and evaluationGetting startedStep 0: Check your setupStep 1: Text and code retrievalStep 2: Cross-modal searchStep 3: Matryoshka truncationStep 4: Code searchChoosing your configurationConclusion Specifications Specification EmbeddingGemma 2 Base model Gemma 4 License Apache 2.0 Output dimension 768, truncatable to 512, 256, 128 Context window 8,192 tokens, shared across modalities Modalities Text, code, images, video, audio Parameters 270M text-only to 740M full multimodal Released October 6, 2026 How it works under the hood The usual way to search across mixed content is to run one model per content type and stitch the results together afterwards. That means separate indexes, separate score ranges, and no reliable way to compare a photo against a paragraph. EmbeddingGemma 2 removes that problem by sending every content type through one backbone. Each modality gets its own front-end encoder, but the output always lands in the same 768-dimensional space. Architecture diagram, Google Developers Blog. The three encoders Encoder Size Handles Built on Text and code 270M, the base Plain text and source code, up to 8,192 tokens An adapted Gemma 4 decoder Vision +170M Photos, charts, slides, PDF pages, and video frames A dedicated vision encoder Audio +300M Speech and ambient sound, fed in as raw audio A dedicated audio encoder The text encoder is the base and is always present. Vision and audio are additions on top of it, which is where the four parameter counts come from. Why modular loading matters One checkpoint, four ways to load it. You are not choosing between four different models. There is one set of weights, and you decide at load time which encoders get read into memory. Skipped encoders cost nothing, on disk or in RAM. Because the output space is identical in all four cases, a query embedded with the 270M text setup can be matched against documents embedded with the full 740M model. Two practical consequences: Start text-only and add images later without re-embedding anything you already indexed. Run a small config on an edge device and a large one on a server, against the same index. Pairing with Gemma 4 If you run Gemma 4 as the generator in an on-device RAG stack, the two models share a text tokenizer and the same audio encoder design. That overlap is loaded once rather than twice, which matters when the constraint is phone memory rather than server memory. Benchmarks and evaluation What Google published Benchmark Result MTEB (Code) 14% higher than EmbeddingGemma 1 Multilingual text Retains EmbeddingGemma 1 accuracy Image, video, audio retrieval New capability, not present in version 1 Google published the MTEB (Code) gain as a percentage improvement rather than absolute scores, so there is no single number to compare against other models directly. Quality retention under truncation Dimension Text and code Image, video, speech Storage per 1M vectors 768d baseline baseline 1,465 MB 512d no stated loss no stated loss 977 MB 256d near baseline roughly 95% 488 MB 128d roughly 90% roughly 75% 244 MB Two things to read off that table. Storage figures assume bfloat16, and the media columns fall away faster than text does. Google flags 128d multimodal as the case to test before you ship it, and the 75% figure explains why. What this run measured Results from the five scripts below, on a small test corpus. These are measurements on one corpus, not benchmark scores. Measurement Result 256d versus 768d ranking Identical top-1 and MRR 128d ranking Top-1 held, MRR fell from 0.667 to 0.656 Mean similarity at 128d Rose 12.6% versus 768d despite identical ranking Image cross-modal margin 0.1154 over the nearest wrong query Audio cross-modal margin 0.0137 over the nearest wrong query Default output precision float32, not bfloat16, so indexes are double the quoted size Getting started First install sentence transformer and other relvant libraries using: pip install -U sentence-transformers[image,audio,video] transformers Requires sentence-transformers 6.1.0 or later. Step 0: Check your setup Reports Python version, library version, available modalities and hardware before you download 740M parameters. File: 00_check_setup.py import sys import importlib import shutil def ok(b): return "OK " if b else "-- " print("=" * 66) print("EmbeddingGemma 2 setup check") print("=" * 66) print(f"\nPython {sys.version.split()[0]} (3.9+ needed)") # --- core library ------------------------------------------------- try: import sentence_transformers as st ver = st.__version__ major, minor = (int(x) for x in ver.split(".")[:2]) good = (major, minor) >= (6, 1) print(f"{ok(good)}sentence-transformers {ver} (need 6.1.0+)") if not good: print(" pip install -U sentence-transformers") except ImportError: print("-- sentence-transformers NOT INSTALLED") print( " pip install -U sentence-transformers[image,audio,video] " "transformers" ) sys.exit(1) # --- which modalities can actually run --------------------------- print("\nModality support:") mods = { "text / code": [], # always available "images": ["PIL"], "audio": ["soundfile", "librosa"], "video": ["decord"], } for name, deps in mods.items(): missing = [ d for d in deps if importlib.util.find_spec(d) is None ] print(f" {ok(not missing)}{name:5} {label: {doc_emb.shape}\n") for q in QUERIES: q_emb = model.encode_query(q) sims = model.similarity(q_emb, doc_emb)[0] best = int(sims.argmax()) print(f"Q: {q}") print(f" score {sims[best]:.4f} -> {DOCS[best][:72]}...") # Show the runner-up so you can see the margin. order = sims.argsort(descending=True) second = int(order[1]) print( f" runner-up {sims[second]:.4f} " f"margin {sims[best] - sims[second]:.4f}\n" ) print( "If the margin is small, your corpus has near-duplicates " "or the query is ambiguous." ) print( "That number is more useful than the raw score " "for debugging retrieval." ) Output: All three queries retrieved the correct document. Margins: Query Top score Margin what causes the northern lights 0.8525 0.1299 how do I reverse a linked list 0.8485 0.0599 why does my database table keep growing 0.6673 0.0407 The database query has the lowest score and thinnest margin because the corpus holds two competing database documents. Margin matters more than raw score. A 0.04 margin means different phrasing could flip the result. Thin margins across a corpus point to chunking or deduplication problems, not the model. Step 2: Cross-modal search Media is passed as a dictionary keyed by modality with no prompt. Only the text query gets a task prompt. File: 02_multimodal.py from sentence_transformers import SentenceTransformer MODEL_ID = "google/embeddinggemma-2" print("Loading full multimodal model (740M)...") model = SentenceTransformer(MODEL_ID) # Media is passed as a dict keyed by modality, with NO prompt. # Only the text query gets a task prompt. image_emb = model.encode({"image": "data/sunset_beach.jpg"}) audio_emb = model.encode({"audio": "data/ocean_waves.wav"}) for query in [ "ocean waves at sunset", "a busy city street", "someone playing piano", ]: q = model.encode_query(query) s_img = float(model.similarity(q, image_emb)[0][0]) s_aud = float(model.similarity(q, audio_emb)[0][0]) print(f"\n{query!r}") print(f" vs image : {s_img:+.4f}") print(f" vs audio : {s_aud:+.4f}") # Interleaved: ONE embedding covering text, photo and video together. # The markers say where each media item sits inside the text. listing_emb = model.encode( { "text": ( "Waterproof trail shoe. " "Grip test on wet rock: " ), "image": "data/trail_shoe.jpg", "video": "data/grip_test.mp4", } ) q = model.encode_query("waterproof trail shoes") print( f"\ninterleaved product listing : " f"{float(model.similarity(q, listing_emb)[0][0]):+.4f}" ) print( "\nThe control to watch: scores for unrelated queries " "should sit clearly lower." ) print( "If 'a busy city street' scores close to 'ocean waves at sunset' " "on the same" ) print( "image, the embedding is not discriminating and retrieval " "will be noisy." ) Output: Measured. Image separates the correct query cleanly. Audio does not. Image: match 0.7026, nearest wrong 0.5872. Margin 0.1154. Thresholdable. Audio: match 0.6466, nearest wrong 0.6329. Margin 0.0137. All three queries inside a 0.045 band. No usable threshold exists on that audio result. Possible causes: the audio encoder is weaker at cross-modal matching, or ocean waves and traffic sit close together because both are broadband noise. Validate audio retrieval on your own clips. Do not assume parity with image. Step 3: Matryoshka truncation Measures what truncation costs on your corpus rather than on Google’s. File: 03_matryoshka.py import numpy as np from sentence_transformers import SentenceTransformer MODEL_ID = "google/embeddinggemma-2" DIMS = [768, 512, 256, 128] model = SentenceTransformer( MODEL_ID, config_kwargs={ "vision_config": None, "audio_config": None, }, ) # Replace these with YOUR corpus and YOUR queries plus known-correct answers. DOCS = [ "Postgres VACUUM reclaims storage from dead tuples after updates and deletes.", "A B-tree index stores keys sorted and supports efficient range scans.", "Connection pooling reuses database connections to avoid per-request handshakes.", "Write-ahead logging records changes before they are applied to data files.", "Table partitioning splits one large table into smaller physical pieces.", "The northern lights are caused by charged particles from the sun.", "Linked list reversal rewires each node's next pointer while walking the list.", "A hash index supports equality lookups but not range queries.", ] # (query, index of the correct document) GOLD = [ ("why does my table keep growing after deletes", 0), ("speed up queries over a date range", 1), ("too many database connections being opened", 2), ("how is durability guaranteed on crash", 3), ] print( f"{'dim':>5} {'storage/1M':>12} {'top-1':>7} " f"{'MRR':>7} {'mean score':>11}" ) print("-" * 52) results = {} for d in DIMS: doc_emb = model.encode_document( DOCS, truncate_dim=d, normalize_embeddings=True, ) hits, rr, scores = 0, [], [] for q, gold_idx in GOLD: q_emb = model.encode_query( q, truncate_dim=d, normalize_embeddings=True, ) sims = model.similarity(q_emb, doc_emb)[0].cpu().numpy() order = np.argsort(-sims) rank = int(np.where(order == gold_idx)[0][0]) + 1 hits += rank == 1 rr.append(1.0 / rank) scores.append(float(sims[gold_idx])) mb = 1_000_000 * d * 2 / 1024**2 # bfloat16 results[d] = ( hits / len(GOLD), float(np.mean(rr)), float(np.mean(scores)), ) print( f"{d:>5} {mb:>9.0f} MB " f"{hits / len(GOLD):>7.2f} " f"{np.mean(rr):>7.3f} " f"{np.mean(scores):>11.4f}" ) print( "\nPick the smallest dimension where top-1 and MRR " "still hold on YOUR data." ) print( "Google's guidance: 256d keeps most text quality, " "128d drops to roughly 90%." ) print( "Your corpus may behave differently, which is the entire " "point of measuring it." ) Output: Left: scores climb as dimensions fall. Right: ranking holds. 256d was free Top-1 and MRR identical at 768d, 512d and 256d. Storage fell from 1,465 MB to 488 MB per million vectors at no measurable cost. At 128d, top-1 held and MRR fell only from 0.667 to 0.656. Scores inflate as you truncate Dimension Mean score Change vs 768d 768d 0.7232 baseline 512d 0.7291 +0.8% 256d 0.7393 +2.2% 128d 0.8145 +12.6% Ranking stayed the same while absolute scores rose 12.6%. Truncating and renormalising concentrates the vector, so cosine similarities drift upward in lower dimensions. A relevance threshold tuned at 768d admits far more at 128d. Re-tune any cutoff when you change dimension. Queries and documents must use the same dimension. Mixing them returns plausible nonsense, not an error. Step 4: Code search Code retrieval is where version 2 improved most. This run indexed the sentence-transformers library against itself, so the correct answers are checkable. File: 04_code_search.py import pathlib import numpy as np from sentence_transformers import SentenceTransformer ROOT = pathlib.Path("./your-repo") # = max_lines: yield start, "\n".join(buf) buf, start = [], i + 1 if buf: yield start, "\n".join(buf) records = [] for f in list(ROOT.rglob("*.py"))[:MAX_FILES]: for line_no, body in chunks(f): if body.strip(): records.append( { "file": str(f.relative_to(ROOT)), "line": line_no, "code": body, } ) print(f"Indexing {len(records)} chunks from {ROOT} ...") emb = model.encode_document( [r["code"] for r in records], truncate_dim=DIM, normalize_embeddings=True, batch_size=32, show_progress_bar=True, ) mb = emb.nbytes / 1024**2 print(f"Index built: {emb.shape}, {mb:.1f} MB in memory\n") for query in [ "where are retry attempts with exponential backoff handled", "code that validates a JWT token", "function that writes results to a CSV file", ]: q = model.encode_query( query, truncate_dim=DIM, normalize_embeddings=True, ) sims = (emb @ q.T).ravel() print(f"Q: {query}") for rank, i in enumerate(np.argsort(-sims)[:3], 1): head = records[i]["code"].strip().splitlines()[0][:62] print( f" {rank}. {sims[i]:.4f} " f"{records[i]['file']}:{records[i]['line']} {head}" ) print() Output: 1. correct All three hits were the overloads of truncate_embeddings in util/tensor.py, the exact function described. 2. correct, ranked third The cos_sim implementation ranked third at 0.8087, behind two docstring examples. Prose describing a concept often outranks the code implementing it, because the query is also prose. Fix: weight by chunk type and demote docstring-only chunks, or re-rank the top twenty with a cross-encoder. 3. failed Top hits were a bare @classmethod decorator and a lone parameter line. Cause is the 2,000-character chunker splitting mid-function, producing fragments with no semantic content. Chunking quality decides code search quality more than the model does. Split on function and class boundaries. Storage detail The index reported 1.2 MB for 1,252 vectors at 256d. At bfloat16 that would be 0.61 MB; at float32 it is 1.22 MB. sentence-transformers returns float32 by default. Google’s storage figures assume bfloat16. A million 768d vectors is 2.9 GB in float32, not 1.5 GB, unless you cast. Choosing your configuration Which encoders to load Your data config_kwargs Parameters Text and code only {'vision_config': None, 'audio_config': None} 270M Text, images, video {'audio_config': None} 440M Text and audio {'vision_config': None} 570M Everything default 740M Disabled encoders are never loaded, so the saving applies to weights and peak memory. Which dimension to use Decide this by what breaks first. If your constraint is recall, stay high. If it is memory or query latency, come down and measure what you lost. Dimension Pick it when 768d or 512d You are searching across media, or a missed result costs more than the extra storage 256d Storage is a real constraint. A sensible default for text-heavy indexes. 128d The index is large and text-only, or this is a cheap first pass before a re-ranker Our Step 3 run found 256d identical to 768d on ranking, so starting at 256d and moving up only if you measure a loss is the cheaper order to work in. Conclusion One checkpoint under Apache 2.0 covers five content types in one vector space, loads only the encoders you need, and trades vector size against quality with one parameter. Run Step 3 first on your own corpus. It decides your index size, memory budget and hosting cost, and no published benchmark can give you that number. Some of the images have been sourced from the developer guide, the model weights, the Gemma documentation, and the Embedding Draw Challenge. Hi , I am Sree Vamsi a passionate Data Science enthusiast currently working at Analytics Vidhya. My journey into data science began with a curiosity for uncovering insights from complex data and has evolved into building end-to-end Generative AI applications, RAG pipelines, agentic AI workflows, and multi-agent systems that solve real-world business problems.
